Pneufit C straight push-in adaptor, R1/2, tube 16 mm - Norgren C01251648

The Norgren C01251648 straight push-in adaptor connects 16 mm OD tubes to an R1/2 port. Key data of the C01251648: tube outside diameter 16 mm, external thread R1/2, operating pressure -0.9 to 10 bar and temperature range -20 to 60 °C.

Benefits

• Releasable stainless steel grab ring: the C01251648 grips nylon or polyurethane tube with 16 mm OD securely.
• Operating pressure -0.9 to 10 bar: the C01251648 works with positive pressure and with vacuum down to -0.9 bar.
• Taper thread R1/2 with pre-applied thread sealant: the C01251648 seals without additional tape.
• Nickel plated brass body: the C01251648 is reliable and corrosion resistant.
• 24 mm hexagon: the C01251648 is fitted with standard tools.

Applications

Typical locations for the C01251648 are cylinders, valves and air preparation units in general industrial automation.

Compliance

According to Norgren, the C01251648 is RoHS compliant.
