Pneufit D straight push-in union, tube 4 mm - Norgren D00200400

The Norgren D00200400 straight push-in union joins two 4 mm OD tubes directly. Key data of the D00200400: tube outside diameter 4 mm, operating pressure -0.9 to 20 bar, temperature range -20 to 98 °C and body material acetal.

Benefits

• Releasable stainless steel grab ring: the D00200400 grips nylon, polyurethane or polyethylene tube with 4 mm OD securely.
• FDA approved acetal body, NSF 51 and 61 certified and compliant with food contact regulation (EC) 1935/2004: the D00200400 is made for contact with food.
• Operating pressure -0.9 to 20 bar: the D00200400 works with positive pressure and with vacuum down to -0.9 bar.
• For compressed air and liquids: the D00200400 can be used in a temperature range of -20 to 98 °C.

Applications

Norgren lists food and beverage, water, medical and analytical equipment for fluid and gas control as fields of use for the D00200400.

Compliance

According to Norgren, the D00200400 is RoHS compliant.
