Pneufit C swivel tee adaptor, R1/2, tube 12 mm - Norgren C01671248

The Norgren C01671248 swivel tee adaptor connects two 12 mm OD tubes to an R1/2 port. Key data of the C01671248: tube outside diameter 12 mm, external thread R1/2, operating pressure -0.9 to 10 bar and temperature range -20 to 60 °C.

Benefits

• Releasable stainless steel grab ring: the C01671248 grips nylon or polyurethane tube with 12 mm OD securely.
• Operating pressure -0.9 to 10 bar: the C01671248 works with positive pressure and with vacuum down to -0.9 bar.
• Taper thread R1/2 with pre-applied thread sealant: the C01671248 seals without additional tape.
• PBT body with nickel plated brass components: the C01671248 resists corrosion and contamination.
• 21 mm hexagon: the C01671248 is fitted with standard tools.

Applications

Typical locations for the C01671248 are cylinders, valves and air preparation units in general industrial automation.

Compliance

According to Norgren, the C01671248 is RoHS compliant.
