Pneufit C swivel Y adaptor, G1/2, tube 12 mm - Norgren C02881248

The Norgren C02881248 swivel Y adaptor connects two 12 mm OD tubes to a G1/2 port. Key data of the C02881248: tube outside diameter 12 mm, external thread G1/2, operating pressure -0.9 to 10 bar and temperature range -20 to 60 °C.

Benefits

• Releasable stainless steel grab ring: the C02881248 grips nylon or polyurethane tube with 12 mm OD securely.
• Operating pressure -0.9 to 10 bar: the C02881248 works with positive pressure and with vacuum down to -0.9 bar.
• Parallel thread G1/2 with recessed captive O-ring for fast sealing of the C02881248.
• PBT body with nickel plated brass components: the C02881248 resists corrosion and contamination.
• 24 mm hexagon: the C02881248 is fitted with standard tools.

Applications

Typical locations for the C02881248 are cylinders, valves and air preparation units in general industrial automation.

Compliance

According to Norgren, the C02881248 is RoHS compliant.
