Pneufit C straight female bulkhead adaptor, G1/2, bulkhead thread M22, tube 12 mm - Norgren C02321248
The Norgren C02321248 straight female bulkhead adaptor takes 12 mm OD tubes through a wall or panel and connects them to a G1/2 male thread. Key data of the C02321248: tube outside diameter 12 mm, bulkhead thread M22, internal thread G1/2 and operating pressure -0.9 to 10 bar.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren C02321248 straight female bulkhead adaptor takes 12 mm OD tubes through a wall or panel and connects them to a G1/2 male thread. Key data of the C02321248: tube outside diameter 12 mm, bulkhead thread M22, internal thread G1/2 and operating pressure -0.9 to 10 bar.
Benefits
- Releasable stainless steel grab ring: the C02321248 grips nylon or polyurethane tube with 12 mm OD securely.
- Operating pressure -0.9 to 10 bar: the C02321248 works with positive pressure and with vacuum down to -0.9 bar.
- Nickel plated brass body: the C02321248 is reliable and corrosion resistant.
Applications
Typical locations for the C02321248 are cylinders, valves and air preparation units in general industrial automation.
Compliance
According to Norgren, the C02321248 is RoHS compliant.
Technical data
| Manufacturer | Norgren |
|---|---|
| Part number | C02321248 |
| Product type | Straight female bulkhead adaptor |
| Series | Pneufit C |
| Shape | Straight |
| Tube outside diameter | 12 mm |
| Bulkhead thread | M22 |
| Internal thread | G1/2 |
| Operating pressure | -0.9 to 10 bar |
| Medium | compressed air |
| Temperature range | -20 to 60 °C |
| Body material | Nickel plated brass |
| Seal material | Nitrile rubber (NBR) |
| External hexagon | 26 mm / 24 mm |
| Length | 40 mm |
| Width | 30 mm |
| Height | 30 mm |
| Weight | 0.066 kg |
| Application area | general industrial automation |
| Shelf life | 10 years |
| RoHS | compliant |
| Hersteller-Nr | C02321248 |
| Zolltarifnummer | 39174000 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | Nickel-plated brass |
| Thread | G 1/2 |
| For hose OD [mm] | 12 |
| Design | straight shape |
| Thread type | Internal thread |
| Betriebsdruck max [bar] | 10 |
| Temperaturbereich | -20-60 °C |
| Temperature (max.) | 60 |
