Pneufit C swivel Y adaptor, G1/8, tube 10 mm - Norgren C02881018

The Norgren C02881018 swivel Y adaptor connects two 10 mm OD tubes to a G1/8 port. Key data of the C02881018: tube outside diameter 10 mm, external thread G1/8, operating pressure -0.9 to 10 bar and temperature range -20 to 60 °C.

Benefits

• Releasable stainless steel grab ring: the C02881018 grips nylon or polyurethane tube with 10 mm OD securely.
• Operating pressure -0.9 to 10 bar: the C02881018 works with positive pressure and with vacuum down to -0.9 bar.
• Parallel thread G1/8 with recessed captive O-ring for fast sealing of the C02881018.
• PBT body with nickel plated brass components: the C02881018 resists corrosion and contamination.
• 17 mm hexagon: the C02881018 is fitted with standard tools.

Applications

Typical locations for the C02881018 are cylinders, valves and air preparation units in general industrial automation.

Compliance

According to Norgren, the C02881018 is RoHS compliant.
