Pneufit C top port branch adaptor, elbow, R1/4, tube 10 mm - Norgren C0F7J1028

The Norgren C0F7J1028 top port branch adaptor connects 10 mm OD tubes to an R1/4 port. Key data of the C0F7J1028: version 3-fold, tube outside diameter 10 mm, external thread R1/4 and internal thread R1/4.

Benefits

• Releasable stainless steel grab ring: the C0F7J1028 grips nylon or polyurethane tube with 10 mm OD securely.
• Operating pressure -0.9 to 10 bar: the C0F7J1028 works with positive pressure and with vacuum down to -0.9 bar.
• Taper thread R1/4 with pre-applied thread sealant: the C0F7J1028 seals without additional tape.
• PBT body with nickel plated brass components: the C0F7J1028 resists corrosion and contamination.
• 17 mm hexagon: the C0F7J1028 is fitted with standard tools.

Applications

Typical locations for the C0F7J1028 are cylinders, valves and air preparation units in general industrial automation.

Compliance

According to Norgren, the C0F7J1028 is RoHS compliant.
