Straight push-on female adaptor G3/8, for 8/6 mm tube, 24 series - Norgren 242260838
Norgren 242260838 screws onto a male thread with its G3/8 female thread and takes a tube with 8/6 mm (OD/ID). It works at -0.9 to 15 bar and from -20 to 80 °C, with a body made of nickel-plated brass, part number 242260838.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Norgren 242260838 is a straight push-on female adaptor from the 24 series with G3/8 female thread and 8/6 mm tube (OD/ID). Norgren 242260838 screws onto a male thread with its G3/8 female thread and takes a tube with 8/6 mm (OD/ID). It works at -0.9 to 15 bar and from -20 to 80 °C, with a body made of nickel-plated brass, part number 242260838.
Benefits
- Operating pressure -0.9 to 15 bar
- Operating temperature -20 to 80 °C
- Body made of nickel-plated brass
- Also suitable for vacuum systems
- Quick connection of pneumatic circuits
- Neat, compact design
Applications
Norgren 242260838 is used in general industrial automation, for example on cylinders, valves and air preparation units. Norgren 242260838 is made in Italy.
Standards and compliance
According to the manufacturer, Norgren 242260838 is RoHS compliant and contains an SVHC substance under REACH.
Technical data
| Manufacturer | Norgren |
|---|---|
| Manufacturer part number | 242260838 |
| Product type | Straight push-on female adaptor |
| Series | 24 series |
| Shape | straight |
| Tube OD/ID | 8/6 mm |
| Internal thread | G3/8 |
| Operating pressure | -0.9 to 15 bar |
| Temperature range | -20 to 80 °C |
| Body material | nickel-plated brass |
| Medium | compressed air |
| Application area | general industrial automation |
| RoHS | compliant |
| REACH | SVHC substance present |
| Country of origin | Italy |
| Weight | 0.039 kg |
| Customs tariff number | 74122000 |
| Hersteller-Nr | 242260838 |
| Zolltarifnummer | 74122000 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Bauform | gerade |
| Gewinde innen | G3/8 |
| Thread | G 3/8 IG |
| For hose OD [mm] | 8 / 6 |
| Housing material | Nickel-plated brass |
| Betriebsdruck max [bar] | 15 |
| Pneumatic connection | G3/8 IG |
| Temperaturbereich | -20-80 °C |
