Pneufit C branch adaptor, elbow, R3/8, tube 10 mm - Norgren C0N701038

The Norgren C0N701038 branch adaptor connects 10 mm OD tubes to an R3/8 port. Key data of the C0N701038: version 2-fold, tube outside diameter 10 mm, external thread R3/8 and operating pressure -0.9 to 10 bar.

Benefits

• Releasable stainless steel grab ring: the C0N701038 grips nylon or polyurethane tube with 10 mm OD securely.
• Operating pressure -0.9 to 10 bar: the C0N701038 works with positive pressure and with vacuum down to -0.9 bar.
• Taper thread R3/8 with pre-applied thread sealant: the C0N701038 seals without additional tape.
• PBT body with nickel plated brass components: the C0N701038 resists corrosion and contamination.
• 19 mm hexagon: the C0N701038 is fitted with standard tools.

Applications

Typical locations for the C0N701038 are cylinders, valves and air preparation units in general industrial automation.

Compliance

According to Norgren, the C0N701038 is RoHS compliant.
