Elbow compression union, tube 22 mm, 43 series - Norgren 430402200

Name: Elbow compression union, tube 22 mm, 43 series - Norgren 430402200
Brand: Norgren
SKU: NRG-430402200
Price: 39.73 EUR
Availability: InStock

Norgren ✓ Original product Brand new

The Norgren elbow compression union 430402200 from the 43 series connects tubes with 22 mm outside diameter. Ratings of 430402200: shape elbow, tube outside diameter 22 mm, body material brass, medium compressed air and operating pressure -0.9 to 40 bar. Advantage of 430402200: rugged and durable.

Net

€39.73

excl. VAT

Item NRG-430402200

Manufacturer no. 430402200

Question about this item

Datasheet (PDF)

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

Benefits

Rugged and durable
Supplied assembled with tubing sleeves, nuts and matching seals
Operating pressure -0.9 to 40 bar, so vacuum is covered as well
Usable at -40 to 200 °C
Body made of brass

Applications

Applications of 430402200: general industrial automation, rigid tube lines in metal or plastic tubing.

Technical data

Manufacturer	Norgren
Order number	430402200
Series	43
Product type	elbow compression union
Shape	elbow
Tube outside diameter	22 mm
Body material	brass
Medium	compressed air
Operating pressure	-0.9 to 40 bar
Operating temperature	-40 to 200 °C
Dimensions L x W x H	65.4 x 65.4 x 41.6 mm
Weight	0.29 kg
RoHS	compliant
Customs tariff number	74122000
Hersteller-Nr	430402200
Zolltarifnummer	74122000
GPSR Herstellerdaten	Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
Artikelzustand	New
Artikel-Authentizität	Original product
Tube OD [mm]	22
Housing material	Brass
Betriebsdruck max [bar]	40
Temperaturbereich	-40-200 °C
