Banjo elbow push-on fitting, tube 5/3 mm, G1/8, 24 series - Norgren 24A510518
The Norgren banjo elbow push-on fitting 24A510518 from the 24 series connects tubing with 5 mm outside diameter to a G1/8 port. Key figures of 24A510518: shape elbow, tube od / id 5 / 3 mm, thread G1/8 male, body material nickel-plated brass and operating pressure -0.9 to 15 bar. Advantage of 24A510518: suitable for vacuum systems.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren banjo elbow push-on fitting 24A510518 from the 24 series connects tubing with 5 mm outside diameter to a G1/8 port. Key figures of 24A510518: shape elbow, tube od / id 5 / 3 mm, thread G1/8 male, body material nickel-plated brass and operating pressure -0.9 to 15 bar. The weight of 24A510518 is 0.03 kg.
Benefits
- Suitable for vacuum systems
- Neat, compact design
- Precision machined for reliability
- Corrosion resistant
- Barb shape grips the tube even when the fitting is only hand-tightened
- For confined spaces with tight bend radii
Applications
Applications of 24A510518: general industrial automation, tubing of pneumatic controls and vacuum circuits.
Technical data
| Manufacturer | Norgren |
|---|---|
| Order number | 24A510518 |
| Series | 24 |
| Product type | banjo elbow push-on fitting |
| Shape | elbow |
| Tube OD / ID | 5 / 3 mm |
| Thread | G1/8 male |
| Body material | nickel-plated brass |
| Operating pressure | -0.9 to 15 bar |
| Operating temperature | -20 to 80 °C |
| External hex | 14 mm |
| Dimensions L x W x H | 31.35 x 28 x 15.7 mm |
| Weight | 0.03 kg |
| RoHS | compliant |
| Customs tariff number | 74122000 |
| Hersteller-Nr | 24A510518 |
| Zolltarifnummer | 74122000 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| For hose OD [mm] | 5 |
| Housing material | Nickel-plated brass |
| Thread type | External thread |
| Betriebsdruck max [bar] | 15 |
| Pneumatic connection | G1/8 AG |
| Temperaturbereich | -20-80 °C |
