Push-in union elbow, for 10 mm tube, Pneufit 10, nickel-plated brass - Norgren 100401000

The Norgren 100401000 push-in union elbow takes tube with 10 mm outside diameter.

Benefits in use

• With an operating pressure of -0.9 to 18 bar, the 100401000 also suits vacuum lines.
• The permitted temperature range of the 100401000 is -20 to 80 °C.
• The body of the 100401000 is made of nickel-plated brass and is corrosion resistant.
• The 100401000 uses NBR as sealing material.
• Further features of the 100401000: retained collet with positive tube anchorage, silicone-free O-ring seals as well as easy tube insertion.
• With a 13 mm across-flats size, the 100401000 fits with standard tools.

Applications

The 100401000 is used for quick assembly of pneumatic circuits: the tube is simply pushed in and released again by pressing the collet.
