Bulkhead compression connector, 12 mm tube OD, 43 series - Norgren 430291200
Secure, releasable tube connection: the Norgren 430291200 bulkhead compression connector for 12 mm tube OD and M18 bulkhead thread. Key data of the 430291200: operating pressure -0.9 to 100 bar, temperature range -40 to 200 °C, brass body.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Norgren 430291200 is a bulkhead compression connector for 12 mm tube OD and M18 bulkhead thread from the 43 series. Norgren specifies an operating pressure of -0.9 to 100 bar and a temperature range of -40 to 200 °C for the 430291200. The body of the 430291200 is made of brass.
Benefits
- Usable from -0.9 bar (vacuum) up to 100 bar
- Temperature range -40 to 200 °C
- Rugged and durable
- Supplied assembled with tubing sleeve, nut and appropriate seals
- RoHS compliant according to Norgren
Applications
The Norgren 430291200 connects compressed-air lines in machines, systems and pneumatic controls.
Technical data
| Manufacturer part number | 430291200 |
|---|---|
| Manufacturer | Norgren |
| Product type | Bulkhead compression connector |
| Product line | 43 series |
| Shape | straight |
| Tube OD | 12 mm |
| Bulkhead thread | M18 |
| Operating pressure | -0.9 to 100 bar |
| Temperature range | -40 to 200 °C |
| Medium | Compressed air |
| Body material | brass |
| RoHS | compliant |
| Country of origin | Italy |
| Weight | 0.125 kg |
| Customs tariff number | 74122000 |
| Hersteller-Nr | 430291200 |
| Zolltarifnummer | 74122000 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Bauform | Gerade |
| For hose OD [mm] | 12 |
| Housing material | Brass |
| Design | Bulkhead |
| Betriebsdruck max [bar] | 100 |
| Temperaturbereich | -40-200 °C |
| Temperature (max.) | 200 |
