Swivel male elbow push-in adaptor, 12 mm tube OD, G3/8, Pneufit 10 - Norgren 102471238

The Norgren 102471238 is a swivel male elbow push-in adaptor for 12 mm tube OD with G3/8 thread from the Pneufit 10 range. Norgren specifies an operating pressure of -0.9 to 18 bar and a temperature range of -20 to 80 °C for the 102471238. The body of the 102471238 is made of nickel-plated brass, the seals of nitrile rubber (NBR).

Benefits

• Usable from -0.9 bar (vacuum) up to 18 bar
• Temperature range -20 to 80 °C
• Parallel male thread G3/8
• Swivel design, the tube outlet can be aligned after installation
• Compact unit with retained collet and positive tube anchorage
• Silicone-free O-ring seals

Applications

The 102471238 is used when building and servicing pneumatic circuits, for example on valves, cylinders and manifolds.
