Straight male push-in adaptor, 6 mm tube OD, G1/8, Pneufit 10 - Norgren 102250618
Fast tube connection by simply pushing the tube in: the Norgren 102250618 straight male push-in adaptor for 6 mm tube OD with G1/8 thread. The 102250618 at a glance: operating pressure -0.9 to 18 bar, temperature range -20 to 80 °C, nickel-plated brass body.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren 102250618 is a straight male push-in adaptor for 6 mm tube OD with G1/8 thread from the Pneufit 10 range. Norgren specifies an operating pressure of -0.9 to 18 bar and a temperature range of -20 to 80 °C for the 102250618. The body of the 102250618 is made of nickel-plated brass, the seals of nitrile rubber (NBR).
Benefits
- Usable from -0.9 bar (vacuum) up to 18 bar
- Temperature range -20 to 80 °C
- Parallel male thread G1/8
- Hexagon size 12 mm
- Compact unit with retained collet and positive tube anchorage
- Silicone-free O-ring seals
Applications
The Norgren 102250618 connects compressed-air lines in machines, systems and pneumatic controls.
Technical data
| Manufacturer part number | 102250618 |
|---|---|
| Manufacturer | Norgren |
| Product type | Straight male push-in adaptor |
| Product line | Pneufit 10 |
| Shape | straight |
| Tube OD | 6 mm |
| Male thread | G1/8 |
| Hexagon size | 12 mm |
| Internal hexagon | 4 mm |
| Operating pressure | -0.9 to 18 bar |
| Temperature range | -20 to 80 °C |
| Medium | Compressed air |
| Body material | nickel-plated brass |
| Seal material | nitrile rubber (NBR) |
| Length | 25 mm |
| Width | 14 mm |
| RoHS | compliant |
| Country of origin | Italy |
| Weight | 0.0097 kg |
| Customs tariff number | 74122000 |
| Hersteller-Nr | 102250618 |
| Zolltarifnummer | 74122000 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Bauform | Gerade |
| Thread | G 1/8 |
| For hose OD [mm] | 6 |
| Housing material | Nickel-plated brass |
| Thread type | External thread |
| Schlüsselweite [mm] | 12 |
| Betriebsdruck max [bar] | 18 |
| Temperaturbereich | -20-80 °C |
| Temperature (max.) | 80 |
