Side swivel male tee push-in adaptor, 6 mm tube OD, R1/8, Pneufit 10 - Norgren 101680618

Norgren 101680618 is a side swivel male tee push-in adaptor for 6 mm tube OD with R1/8 thread from the Pneufit 10 range. Norgren specifies an operating pressure of -0.9 to 18 bar and a temperature range of -20 to 80 °C for the 101680618. The body of the 101680618 is made of nickel-plated brass, the seals of nitrile rubber (NBR).

Benefits

• Usable from -0.9 bar (vacuum) up to 18 bar
• Temperature range -20 to 80 °C
• Taper male thread R1/8 for a tight screw-in seal
• Swivel design, the tube outlet can be aligned after installation
• Compact unit with retained collet and positive tube anchorage
• Silicone-free O-ring seals

Applications

Typical locations for the 101680618 are compressed-air distribution as well as valve and cylinder ports in machine and plant building.
