Straight male stem adaptor, R1/4, 6 mm stem, Pneufit 10 - Norgren 101150628
Stem for push-in ports: the Norgren 101150628 straight male stem adaptor with R1/4 thread and 6 mm stem. Key data of the 101150628: operating pressure -0.9 to 18 bar, temperature range -20 to 80 °C, nickel-plated brass body.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren 101150628 is a straight male stem adaptor with R1/4 thread and 6 mm stem from the Pneufit 10 range. Norgren specifies an operating pressure of -0.9 to 18 bar and a temperature range of -20 to 80 °C for the 101150628. The body of the 101150628 is made of nickel-plated brass.
Benefits
- Usable from -0.9 bar (vacuum) up to 18 bar
- Temperature range -20 to 80 °C
- Taper male thread R1/4 for a tight screw-in seal
- Hexagon size 14 mm
- Silicone-free O-ring seals
- For quick and simple assembly of pneumatic circuits
Applications
Typical locations for the 101150628 are compressed-air distribution as well as valve and cylinder ports in machine and plant building.
Technical data
| Manufacturer part number | 101150628 |
|---|---|
| Manufacturer | Norgren |
| Product type | Straight male stem adaptor |
| Product line | Pneufit 10 |
| Shape | straight |
| Stem OD | 6 mm |
| Male thread | R1/4 |
| Hexagon size | 14 mm |
| Operating pressure | -0.9 to 18 bar |
| Temperature range | -20 to 80 °C |
| Medium | Compressed air |
| Body material | nickel-plated brass |
| Length | 35 mm |
| Width | 16.2 mm |
| RoHS | compliant |
| Country of origin | Italy |
| Weight | 0.019 kg |
| Customs tariff number | 74122000 |
| Hersteller-Nr | 101150628 |
| Zolltarifnummer | 74122000 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Bauform | Gerade |
| Thread | R 1/4 |
| Housing material | Nickel-plated brass |
| Thread type | External thread |
| Schlüsselweite [mm] | 14 |
| Betriebsdruck max [bar] | 18 |
| Temperaturbereich | -20-80 °C |
| Temperature (max.) | 80 |
