Banjo elbow, compression type, 4 mm OD tube, G 1/8 male - Norgren 43A510418
Norgren 43A510418 is a banjo elbow from the 43 series in compression design for 4 mm OD tube and G 1/8 male thread. Norgren 43A510418 is fixed in the G 1/8 port with a banjo bolt and can be turned about the bolt axis into the required direction.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Norgren 43A510418 is a banjo elbow from the 43 series in compression design for 4 mm OD tube and G 1/8 male thread. Norgren 43A510418 is fixed in the G 1/8 port with a banjo bolt and can be turned about the bolt axis into the required direction.
The banjo is made of brass and is designed for compressed air at -0.9 to 100 bar and across a temperature range of -40 to 200 °C.
Benefits
- Pressure range -0.9 to 100 bar
- Temperature range -40 to 200 °C
- Rugged and durable
- Supplied assembled with tubing sleeves, nuts and seals
Applications
The banjo suits fixed tube lines in machines and plant in general industrial automation.
Standards and compliance
According to the manufacturer, Norgren 43A510418 is RoHS compliant.
Technical data
| Manufacturer | Norgren |
|---|---|
| Manufacturer part number | 43A510418 |
| Product type | Banjo elbow, compression type, 4 mm OD tube, G 1/8 male |
| Series | 43 |
| Connection type | compression |
| Tube OD | 4 mm |
| Thread | G 1/8 male |
| Body material | brass |
| Medium | compressed air |
| Operating pressure | -0.9 to 100 bar |
| Temperature range | -40 to 200 °C |
| Dimensions L x W x H | 31 x 31 x 30.35 mm |
| Weight | 0.037 kg |
| Customs tariff number | 74122000 |
| Hersteller-Nr | 43A510418 |
| Zolltarifnummer | 74122000 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Tube OD [mm] | 4 |
| Housing material | Brass |
| Thread type | External thread |
| Betriebsdruck max [bar] | 100 |
| Temperaturbereich | -40-200 °C |
