5/2 solenoid valve for VS26 valve island, bistable, 26 mm width, 24 V DC, softseal - Norgren VS26S511DF213A

The Norgren VS26S511DF213A 5/2 solenoid valve controls cylinders and actuators directly from the VS26 valve island. Data of the VS26S511DF213A at a glance: bistable, 24 V DC, 1350 l/min and 2 to 10 bar.

Benefits

• Bistable: the VS26S511DF213A holds its last switched position without a continuous signal.
• Flow of 1350 l/min: the reference value for sizing cylinder speed on the VS26S511DF213A.
• Operating pressure of 2 to 10 bar on the VS26S511DF213A.
• Power consumption 1.2 W at 24 V DC: the VS26S511DF213A puts little load on the control outputs.
• B10 value of 12,000,000 cycles: a documented figure for the service life of the VS26S511DF213A.
• IP65, NEMA 4 protection: the VS26S511DF213A is dust-tight and protected against water jets.

Applications

Typical applications of the VS26S511DF213A are assembly and handling systems and the servicing of existing VS26 valve islands.
