End plate set type D, G1, ISO 3, CQM/22000 series - Norgren CQM/22354/3/22

Name: End plate set type D, G1, ISO 3, CQM/22000 series - Norgren CQM/22354/3/22
Brand: Norgren
SKU: NRG-CQM/22354/3/22
Price: 79.90 EUR
Availability: InStock

Norgren ✓ Original product Brand new

The end plate set type D closes off a row of valves at the side. Norgren CQM/22354/3/22 is an end plate set type D with G1 port and in size ISO 3.

Net

€79.90

excl. VAT

Item NRG-CQM/22354/3/22

Manufacturer no. CQM/22354/3/22

Question about this item

Datasheet (PDF)

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The Norgren end plate set type D CQM/22354/3/22 has a G1 port and comes in size ISO 3. The plate from the CQM/22000 series closes off a row of valves at the side.

Applications

The plate with NBR seals is used when building or extending valve groups.

Technical data

Manufacturer	Norgren
Manufacturer part number	CQM/22354/3/22
Product type	End plate set type D
Series	CQM/22000
Product family	ISO Star
Port size	G1
ISO size	ISO 3
Medium	compressed air
Seal material	nitrile rubber (NBR)
Dimensions L x W x H	190 x 58 x 30 mm
Weight	0.65 kg
Standards	ISO 5599-1
Hersteller-Nr	CQM/22354/3/22
Zolltarifnummer	84819000
GPSR Herstellerdaten	Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
Artikelzustand	New
Artikel-Authentizität	Original product
Norm	ISO 5599-1
Pneumatic connection	G1
