5/2 solenoid valve, monostable, G1/4, 24 V DC, 4.8 W, Herion - Norgren 2623000305202400

The Norgren 5/2 solenoid valve 2623000305202400 has a G1/4 port, is designed for 24 V DC and operates from 1 to 10 bar. The valve from the 26230 series returns to its normal position on its own once the control signal is removed.

Benefits

• Operating pressure 1 to 10 bar
• Flow 1325 l/min for fast filling and exhausting
• Electrical connection DIN EN 175301-803 form B for common connectors
• B10 value 10,000,000 cycles for maintenance planning
• Power consumption 4.8 W at the coil
• Ambient temperature -10 to 50 °C

Applications

The valve controls double-acting actuators in assembly, packaging and handling systems.
