One-way flow control valve, G1/4, die-cast aluminium - Norgren T1000C2800

Name: One-way flow control valve, G1/4, die-cast aluminium - Norgren T1000C2800
Brand: Norgren
SKU: NRG-T1000C2800
Price: 36.33 EUR
Availability: InStock

Norgren ✓ Original product Brand new

Throttles the air flow in one direction while the return flow passes freely. Norgren T1000C2800 is a one-way flow control valve with G1/4 port and rated for 1 to 10 bar.

Net

€36.33

excl. VAT

Item NRG-T1000C2800

Manufacturer no. T1000C2800

Question about this item

Datasheet (PDF)

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The Norgren one-way flow control valve T1000C2800 has a G1/4 port and operates from 1 to 10 bar. The valve from the T1000 series reaches a Kv value of 0.6 m³/h.

Benefits

Operating pressure 1 to 10 bar
Kv value 0.6 m³/h as the sizing figure for the line
Ambient temperature -20 to 80 °C
Dimensions 45 x 19 x 61.5 mm

Applications

The valve with NBR seals controls cylinder speed in one direction of travel.

Technical data

Manufacturer	Norgren
Manufacturer part number	T1000C2800
Product type	One-way flow control valve
Series	T1000
Port size	G1/4
Operating pressure	1 to 10 bar
Kv value	0.6 m³/h
Medium	compressed air
Ambient temperature	-20 to 80 °C
Body material	die-cast aluminium
Seal material	nitrile rubber (NBR)
Dimensions L x W x H	45 x 19 x 61.5 mm
RoHS	compliant
Weight	0.065 kg
Hersteller-Nr	T1000C2800
Zolltarifnummer	84812090
GPSR Herstellerdaten	Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
Artikelzustand	New
Artikel-Authentizität	Original product
Housing material	Die-cast aluminium
Function	Throttle check valve function
Betriebsdruck max [bar]	10
Pneumatic connection	G1/4
Temperaturbereich	-20-80 °C
