Non-return valve, G3/8, die-cast aluminium - Norgren T55C3800

Name: Non-return valve, G3/8, die-cast aluminium - Norgren T55C3800
Brand: Norgren
SKU: NRG-T55C3800
Price: 26.52 EUR
Availability: InStock

Norgren ✓ Original product Brand new

Reaches a Kv value of 1.92 m³/h. Norgren T55C3800 is a non-return valve with G3/8 port and rated for 0.1 to 10 bar. Works across 0.1 to 10 bar.

Net

€26.52

excl. VAT

Item NRG-T55C3800

Manufacturer no. T55C3800

Question about this item

Datasheet (PDF)

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The Norgren non-return valve T55C3800 has a G3/8 port and operates from 0.1 to 10 bar. The valve reaches a Kv value of 1.92 m³/h.

Benefits

Operating pressure 0.1 to 10 bar
Kv value 1.92 m³/h as the sizing figure for the line
Ambient temperature -20 to 80 °C
Dimensions 63 x 26 x 26 mm

Applications

The valve from the T55 series holds pressure in a line section.

Technical data

Manufacturer	Norgren
Manufacturer part number	T55C3800
Product type	Non-return valve
Series	T55
Port size	G3/8
Operating pressure	0.1 to 10 bar
Kv value	1.92 m³/h
Medium	compressed air
Ambient temperature	-20 to 80 °C
Body material	die-cast aluminium
Seal material	nitrile rubber (NBR)
Dimensions L x W x H	63 x 26 x 26 mm
RoHS	compliant
Weight	0.055 kg
Hersteller-Nr	T55C3800
Zolltarifnummer	84813099
GPSR Herstellerdaten	Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
Artikelzustand	New
Artikel-Authentizität	Original product
Housing material	Die-cast aluminium
Function	Check function
Betriebsdruck max [bar]	10
Pneumatic connection	G3/8
Temperaturbereich	-20-80 °C
