Base plate, 10 stations, G1/4, for V44/V45 - Norgren V70510-BA0

Name: Base plate, 10 stations, G1/4, for V44/V45 - Norgren V70510-BA0
Brand: Norgren
SKU: NRG-V70510-BA0
Price: 338.76 EUR
Availability: InStock

Norgren ✓ Original product Brand new

The base plate from the V44/V45 series is used when building or extending valve groups. Norgren V70510-BA0 is a base plate with G1/4 port and with 10 valve stations.

Net

€338.76

excl. VAT

Item NRG-V70510-BA0

Manufacturer no. V70510-BA0

Question about this item

Datasheet (PDF)

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The Norgren base plate V70510-BA0 provides 10 valve stations. Permitted ambient temperatures are -15 to 50 °C.

Benefits

VDMA 24 563 standard for uniform mounting dimensions
Ambient temperature -15 to 50 °C
10 valve stations on one plate
Dimensions 65 x 32 x 299 mm

Applications

The plate is used when building or extending valve groups.

Technical data

Manufacturer	Norgren
Manufacturer part number	V70510-BA0
Product type	Base plate
Series	V44/V45
Product family	Mini ISO Valves
Port size	G1/4
Stations	10
Medium	compressed air
Ambient temperature	-15 to 50 °C
Dimensions L x W x H	65 x 32 x 299 mm
Standards	VDMA 24 563
Weight	1.4 kg
Hersteller-Nr	V70510-BA0
Zolltarifnummer	84819000
GPSR Herstellerdaten	Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
Artikelzustand	New
Artikel-Authentizität	Original product
Anzahl Stationen [Stk]	10
Pneumatic connection	G1/4
