5/3-way valve all ports blocked, G1/4 port, hand lever - Norgren X3363702

The Norgren X3363702 is a 5/3-way valve with all ports blocked in the centre position (APB) and G1/4 ports. The X3363702 is operated by hand via a lever, each of the three positions is selected directly.

Benefits in use

• In the centre position the X3363702 blocks all ports, so a connected cylinder is held in position.
• Actuation of the X3363702: lever / lever / lever.
• The X3363702 operates from -0.9 to 10 bar and can therefore also be used with vacuum.
• With a flow rate of 965 l/min the X3363702 supplies larger cylinders quickly.
• The X3363702 has a median B10 value of 1 million switching cycles according to ISO 19973.
• The X3363702 is rated for ambient temperatures from 0 to 70 °C.

Applications

The X3363702 controls double-acting cylinders that need to stop in intermediate positions.
