5/2-way valve pressure priority, G1/4 port, air pilot operated - Norgren X3065202

The Norgren X3065202 is a 5/2-way valve with pressure priority switching and G1/4 ports. The X3065202 is switched by pilot air and needs no electrical supply at the point of installation.

Benefits in use

• Actuation of the X3065202: pressure priority / pilot.
• The X3065202 operates from -0.9 to 10 bar and can therefore also be used with vacuum.
• The pilot pressure of the X3065202 is 4 to 10 bar.
• With a flow rate of 965 l/min the X3065202 supplies larger cylinders quickly.
• The X3065202 has a B10 value of 1 million switching cycles.
• The X3065202 is rated for ambient temperatures from 0 to 80 °C.

Applications

Typical tasks for the X3065202 are extending and retracting double-acting cylinders and controlling pneumatic rotary actuators.
