5/2-Directional Valve-Bist G1/2 Ohne Magnet - Norgren V63D511A-A2000

Images are examples, some edited with AI. The technical data are authoritative. AI notice

5/2-way valve bistable, G1/2 port, without solenoid coil - Norgren V63D511A-A2000

Name: 5/2-way valve bistable, G1/2 port, without solenoid coil - Norgren V63D511A-A2000
Brand: Norgren
SKU: NRG-V63D511A-A2000
Price: 283.06 EUR
Availability: InStock

Norgren ✓ Original product Brand new

The Norgren V63D511A-A2000 is a bistable 5/2-way valve, with G1/2 ports. The V63D511A-A2000 is supplied without a solenoid coil, so the coil can be chosen to match the existing control voltage. The pressure range of the V63D511A-A2000 is 2 to 10 bar.

Net

€283.06

excl. VAT

Item NRG-V63D511A-A2000

Manufacturer no. V63D511A-A2000

Question about this item

Datasheet (PDF)

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The Norgren V63D511A-A2000 is a bistable 5/2-way valve, with G1/2 ports. The V63D511A-A2000 is supplied without a solenoid coil, so the coil can be chosen to match the existing control voltage.

Benefits in use

As a bistable valve the V63D511A-A2000 holds its switching position after the signal is removed.
Actuation of the V63D511A-A2000: solenoid / solenoid.
The V63D511A-A2000 works within a pressure range of 2 to 10 bar.
The V63D511A-A2000 is rated for ambient temperatures from -10 to 50 °C.
The body of the V63D511A-A2000 is made of die-cast aluminium.

Applications

Typical tasks for the V63D511A-A2000 are extending and retracting double-acting cylinders and controlling pneumatic rotary actuators.

Technical data

Manufacturer	Norgren
Order number	V63D511A-A2000
Type	Directional control valve
Valve function	5/2
Switching behaviour	bistable
Actuation	solenoid / solenoid
Solenoid coil	not included
Port	G1/2
Medium	Compressed air
Pressure range	2 to 10 bar
Ambient temperature	-10 to 50 °C
Body	die-cast aluminium
Weight	0.85 kg
Series	V60 to V63
Hersteller-Nr	V63D511A-A2000
Zolltarifnummer	84818059
GPSR Herstellerdaten	Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
Artikelzustand	New
Artikel-Authentizität	Original product
Ausführung	ohne Magnetspule
Housing material	Die-cast aluminium
Function	5/2 bistable
Actuation type	Electrical
Betriebsdruck max [bar]	10
Pneumatic connection	G1/2
Temperaturbereich	-10-50 °C
Temperature (max.)	50
