2x3/2-way valve NC, G1/4 port, solenoid 24 V DC - Norgren V61BA11A-A213J

The Norgren V61BA11A-A213J is a 2x3/2-way valve, normally closed (NC), with G1/4 ports. The V61BA11A-A213J is switched by a 24 V DC solenoid.

Benefits in use

• The NC switching function of the V61BA11A-A213J clearly defines the home position.
• The V61BA11A-A213J combines two 3/2-way functions in one body and occupies just one valve position.
• Actuation of the V61BA11A-A213J: solenoid / spring.
• The V61BA11A-A213J works within a pressure range of 2 to 8 bar.
• The V61BA11A-A213J is rated for ambient temperatures from -10 to 50 °C.
• The body of the V61BA11A-A213J is made of die-cast aluminium.

Applications

The V61BA11A-A213J handles two separate 3/2 switching tasks, for example two single-acting cylinders or both chambers of a double-acting cylinder.
