3/2-way valve NC, G3/8 port, air pilot operated - Norgren V62C4DDA-XA020
The Norgren V62C4DDA-XA020 is a 3/2-way valve, normally closed (NC), with G3/8 ports. The V62C4DDA-XA020 is switched by pilot air and needs no electrical supply at the point of installation. The pressure range of the V62C4DDA-XA020 is -0.9 to 10 bar.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren V62C4DDA-XA020 is a 3/2-way valve, normally closed (NC), with G3/8 ports. The V62C4DDA-XA020 is switched by pilot air and needs no electrical supply at the point of installation.
Benefits in use
- The NC switching function of the V62C4DDA-XA020 clearly defines the home position.
- Actuation of the V62C4DDA-XA020: air pilot / air pilot.
- The V62C4DDA-XA020 operates from -0.9 to 10 bar and can therefore also be used with vacuum.
- IP65 protection guards the V62C4DDA-XA020 against dust and water jets.
- The V62C4DDA-XA020 has a median B10 value of 8 million switching cycles according to ISO 19973.
- The V62C4DDA-XA020 is rated for ambient temperatures from -10 to 50 °C.
Applications
The V62C4DDA-XA020 controls single-acting cylinders and pressurises or exhausts downstream consumers.
Technical data
| Manufacturer | Norgren |
|---|---|
| Order number | V62C4DDA-XA020 |
| Type | Directional control valve |
| Valve function | 3/2 |
| Switching function | normally closed (NC) |
| Actuation | air pilot / air pilot |
| Port | G3/8 |
| Medium | Compressed air |
| Pressure range | -0.9 to 10 bar |
| Ambient temperature | -10 to 50 °C |
| Body | die-cast aluminium |
| Protection class | IP65 |
| B10 value | 8 million cycles (median, ISO 19973) |
| Dimensions (H x L x W) | 50 x 190 x 80 mm |
| Weight | 0.55 kg |
| Series | V60 to V63 |
| Hersteller-Nr | V62C4DDA-XA020 |
| Zolltarifnummer | 84818059 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Housing material | Die-cast aluminium |
| Function | 3/2 NC |
| Actuation type | pneumatic |
| Operating conditions | ISO 19973 |
| Betriebsdruck max [bar] | 10 |
| Pneumatic connection | G3/8 |
| Protection rating | IP65 |
| Temperaturbereich | -10-50 °C |
| Temperature (max.) | 50 |
