5/3-way valve all ports blocked, G1/4 port, without solenoid coil - Norgren V61B611A-A3000

The Norgren V61B611A-A3000 is a 5/3-way valve with all ports blocked in the centre position (APB) and G1/4 ports. The V61B611A-A3000 is supplied without a solenoid coil, so the coil can be chosen to match the existing control voltage.

Benefits in use

• In the centre position the V61B611A-A3000 blocks all ports, so a connected cylinder is held in position.
• Actuation of the V61B611A-A3000: solenoid / solenoid.
• The V61B611A-A3000 works within a pressure range of 3 to 10 bar.
• IP65 protection guards the V61B611A-A3000 against dust and water jets.
• The V61B611A-A3000 has a median B10 value of 12 million switching cycles according to ISO 19973.
• The V61B611A-A3000 is rated for ambient temperatures from -10 to 50 °C.

Applications

The V61B611A-A3000 controls double-acting cylinders that need to stop in intermediate positions.
