3/2-way valve NC monostable, G1/2 port, without solenoid coil - Norgren V63D417A-A3000

The Norgren V63D417A-A3000 is a monostable 3/2-way valve, normally closed (NC), with G1/2 ports. The V63D417A-A3000 is supplied without a solenoid coil, so the coil can be chosen to match the existing control voltage.

Benefits in use

• Without a signal the V63D417A-A3000 keeps the flow path closed and returns to its closed home position when the signal drops.
• Actuation of the V63D417A-A3000: solenoid / spring.
• The V63D417A-A3000 works within a pressure range of 3 to 10 bar.
• The V63D417A-A3000 is rated for ambient temperatures from -10 to 50 °C.
• The body of the V63D417A-A3000 is made of die-cast aluminium.

Applications

The V63D417A-A3000 controls single-acting cylinders and pressurises or exhausts downstream consumers.
