End plate D for ISO size 1 valve manifolds, G3/8 port, VDMA version - Norgren CQM/22152/3/22

Name: End plate D for ISO size 1 valve manifolds, G3/8 port, VDMA version - Norgren CQM/22152/3/22
Brand: Norgren
SKU: NRG-CQM/22152/3/22
Price: 65.93 EUR
Availability: InStock

Norgren ✓ Original product Brand new

The Norgren CQM/22152/3/22 end plate closes off the end of a valve manifold. Key data of the CQM/22152/3/22: G3/8 port, ISO size 1.

Net

€65.93

excl. VAT

Item NRG-CQM/22152/3/22

Manufacturer no. CQM/22152/3/22

Question about this item

Datasheet (PDF)

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The Norgren CQM/22152/3/22 end plate closes off the end of a valve manifold. Key data of the CQM/22152/3/22: G3/8 port, ISO size 1.

Applications

The CQM/22152/3/22 is needed when building, extending or repairing valve assemblies.

Standards

According to the manufacturer the CQM/22152/3/22 complies with ISO 5599-1.

Technical data

Product type	end plate
Port	G3/8
ISO size	1
Variant	D
Version	VDMA
Medium	compressed air
Seals	NBR (nitrile rubber)
Standard	ISO 5599-1
Series	CQM/22000
Product family	ISO Star
Dimensions (L x W x H)	110 x 46 x 21 mm
Weight	0.21 kg
Order code	CQM/22152/3/22
Manufacturer	Norgren
Hersteller-Nr	CQM/22152/3/22
Zolltarifnummer	84819000
GPSR Herstellerdaten	Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
Artikelzustand	New
Artikel-Authentizität	Original product
Bauform	Endplatte
Seal material	NBR
Norm	ISO 5599-1
Pneumatic connection	G3/8
