5/2-way valve, bistable, G3/8, air pilot operated - Norgren V62C5DDA-XA020
The Norgren V62C5DDA-XA020 5/2-way valve keeps its last switched position even when the control signal is removed. Key data of the V62C5DDA-XA020: G3/8 port, air pilot operated, operating pressure -0.9 to 10 bar.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren V62C5DDA-XA020 5/2-way valve keeps its last switched position even when the control signal is removed. Key data of the V62C5DDA-XA020: G3/8 port, air pilot operated, operating pressure -0.9 to 10 bar.
Benefits
- 5/2 function, bistable
- operating pressure -0.9 to 10 bar
- temperature range -10 to 50 °C
- B10 value 8,000,000 cycles
- protection class IP65
Applications
The V62C5DDA-XA020 is switched by pilot air, which suits purely pneumatic controls without electrical signals.
Standards
The B10 value of the V62C5DDA-XA020 is determined on the basis of ISO 19973.
Technical data
| Product type | 5/2-way valve |
|---|---|
| Valve function | 5/2 |
| Switching behaviour | bistable |
| Port | G3/8 |
| Actuation / return | air pilot / air pilot |
| Medium | compressed air |
| Operating pressure | -0.9 to 10 bar |
| Ambient temperature | -10 to 50 °C |
| Body material | die-cast aluminium |
| Protection class | IP65 |
| B10 value (median) to ISO 19973 | 8,000,000 cycles |
| Series | V60 to V63 |
| Dimensions (L x W x H) | 190 x 80 x 50 mm |
| Weight | 0.66 kg |
| Order code | V62C5DDA-XA020 |
| Manufacturer | Norgren |
| Hersteller-Nr | V62C5DDA-XA020 |
| Zolltarifnummer | 84818059 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Bauform | 5/2-Wegeventil |
| Housing material | Die-cast aluminium |
| Function | 5/2 bistable |
| Actuation type | pneumatic |
| Operating conditions | ISO 19973 |
| Betriebsdruck max [bar] | 10 |
| Pneumatic connection | G3/8 |
| Protection rating | IP65 |
| Temperaturbereich | -10-50 °C |
