Quick exhaust valve, G1/2, elbow, for rapid exhaust - Norgren T70C4800

The quick exhaust valve with G1/2 port exhausts a cylinder directly at the actuator and so increases piston speed.

The manufacturer specifies an operating pressure of 0.5 to 10 bar and a temperature of -20 to 80 °C for the quick exhaust valve.

Benefits

• 3101 l/min flow of the quick exhaust valve
• kv value 4.2 m³/h of the quick exhaust valve for sizing
• kv value 5.33 m³/h of the quick exhaust valve in the exhaust direction
• up to 10 bar operating pressure of the quick exhaust valve
• -20 to 80 °C operating temperature of the quick exhaust valve

Applications

A typical use of the quick exhaust valve is on large cylinders and long lines where return air would otherwise slow the stroke.
