5/2 directional control valve, G1/4, foot pedal - Norgren X3068202

As a 5/2 directional control valve with G1/4 ports, the valve is operated by hand via a foot pedal and suits operator stations on machines and fixtures. With five ports and two switching positions, the valve X3068202 drives a double-acting cylinder in both directions. Actuation and return of the valve: pedal / spring return.

With a nominal flow of 965 l/min and an operating pressure of -0.9 to 10 bar, the valve X3068202 is rated for compressed air. ISO 19973, the standard for reliability testing of pneumatic components, is stated as the operating condition for the valve X3068202.

Benefits

• 965 l/min nominal flow of the valve X3068202
• -0.9 to 10 bar operating pressure of the valve X3068202
• 0 to 70 °C operating temperature of the valve X3068202
• B10 value of 1,000,000 cycles for the valve X3068202, giving long service intervals

Applications

Typical tasks for the valve X3068202 are controlling cylinders and rotary actuators in machines, fixtures and plants.
