5/2-way valve G1/4, normally closed (NC), air pilot operated - Norgren V61B5DDA-XA020
The Norgren 5/2-way valve V61B5DDA-XA020 controls double-acting pneumatic cylinders and rotary actuators, G1/4 port. The V61B5DDA-XA020 at a glance: normally closed (NC), air pilot operated, pressure range -0.9 to 10 bar. As a genuine Norgren part, the V61B5DDA-XA020 replaces an identical unit without modification.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren 5/2-way valve V61B5DDA-XA020 controls double-acting pneumatic cylinders and rotary actuators, G1/4 port.
Benefits
- Normally closed (NC): without actuation the V61B5DDA-XA020 blocks the flow.
- Pressure range -0.9 to 10 bar according to the manufacturer data for the V61B5DDA-XA020.
- Air pilot operated: the V61B5DDA-XA020 switches on a pilot air signal without any electrical connection.
- Suitable for ambient temperatures of -10 to 50 °C according to the manufacturer data for the V61B5DDA-XA020.
- B10 value (median) to ISO 19973: 12,000,000 cycles for the V61B5DDA-XA020.
- Degree of protection IP65 according to the data sheet of the V61B5DDA-XA020.
Applications
Typical applications for the V61B5DDA-XA020 are packaging machines, assembly and handling systems and the maintenance of existing Norgren installations.
Technical data
| Manufacturer | Norgren |
|---|---|
| Order number | V61B5DDA-XA020 |
| Product type | 5/2-way valve |
| Series | V60-63 |
| Function | 5/2-way |
| Switching function | normally closed (NC) |
| Actuation | pilot air / pilot air |
| Port | G1/4 |
| Medium | Compressed air |
| Pressure range | -0.9 to 10 bar |
| Ambient temperature | -10 to 50 °C |
| Body | die-cast aluminium |
| Degree of protection | IP65 |
| B10 (median) to ISO 19973 | 12,000,000 cycles |
| Dimensions (L x W x H) | 165 x 68 x 42 mm |
| Weight | 0.33 kg |
| Customs tariff number | 84818059 |
| Hersteller-Nr | V61B5DDA-XA020 |
| Zolltarifnummer | 84818059 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Housing material | Die-cast aluminium |
| Actuation type | pneumatic |
| Operating conditions | ISO 19973 |
| Betriebsdruck max [bar] | 10 |
| Pneumatic connection | G1/4 |
| Protection rating | IP65 |
| Temperaturbereich | -10-50 °C |
| Temperature (max.) | 50 |
