5/3 manually actuated valve, centre open exhaust (COE), G1/8, lever, 3 detented positions, 335 l/min - Norgren X3347702

The Norgren Super X X3347702 is a manually actuated 5/3 valve with G1/8 ports and a flow of up to 335 l/min. In the centre position the X3347702 exhausts both working ports, leaving the cylinder free of force. The lever of the X3347702 is detented in all three positions.

Benefits

• Operating pressure from -0.9 to 10 bar, so vacuum is possible
• B10 value of 1,000,000 cycles
• Zinc body, lightweight and corrosion resistant
• Suitable for multi-directional flow and dual supply applications

Applications

The X3347702 controls double-acting cylinders at manual workstations, fixtures and set-up functions.
