Stainless steel pneumatic cylinder ISO 6432, double-acting, 20 mm bore, 125 mm stroke, adjustable cushioning, magnetic piston - Norgren KM/8021/M/125
The Norgren stainless steel pneumatic cylinder KM/8021/M/125 offers 20 mm bore and 125 mm stroke for double-acting motion tasks on compressed air. With 188 N theoretical force and ISO 6432 dimensions the KM/8021/M/125 drops straight into the design.
Net
excl. VAT
€478.32
Item
NRG-KM/8021/M/125
Manufacturer no.
KM/8021/M/125
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren stainless steel pneumatic cylinder KM/8021/M/125 is a double-acting cylinder with a 20 mm bore and 125 mm of stroke.
Benefits
- Dimensions to ISO 6432: the KM/8021/M/125 can be swapped for cylinders of the same standard and size.
- Theoretical force stated by the manufacturer for the KM/8021/M/125: 188 N.
- Barrel in stainless steel 1.4301 (AISI 304) and piston rod in 1.4305 (AISI 303) on the KM/8021/M/125.
- Adjustable cushioning lets you tune the KM/8021/M/125 to load and speed.
- Magnetic piston: the piston position of the KM/8021/M/125 can be sensed with cylinder switches.
- Operating pressure 1 to 10 bar via G1/8 port on the KM/8021/M/125.
Applications
The KM/8021/M/125 suits clamping, pushing and lifting tasks where a stainless steel cylinder is required.
Technical data
| Manufacturer | Norgren |
|---|---|
| Order number | KM/8021/M/125 |
| Design | Stainless steel pneumatic cylinder |
| Series | KM/8000/M |
| Standard | ISO 6432 |
| Operating mode | double-acting |
| Bore | 20 mm |
| Stroke | 125 mm |
| Medium | Compressed air |
| Operating pressure | 1 to 10 bar |
| Ambient temperature | -10 to 80 °C |
| Port | G1/8 |
| Theoretical force | 188 N |
| Cushioning | adjustable cushioning |
| Piston | magnetic |
| Barrel | stainless steel 1.4301 (AISI 304) |
| Piston rod | stainless steel 1.4305 (AISI 303) |
| Piston material | POM |
| Seals | NBR (nitrile rubber) |
| Weight | 0.22 kg |
| Hersteller-Nr | KM/8021/M/125 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Piston Ø [mm] | 20 |
| Stroke [mm] | 125 |
| Seal material | NBR |
| Housing material | Stainless steel 1.4301 |
| Function | double-acting |
| Norm | ISO 6432 |
| Betriebsdruck max [bar] | 10 |
| Pneumatic connection | G1/8 |
| Temperaturbereich | -10-80 °C |
| Temperature (max.) | 80 |
