ISO 6432 stainless steel pneumatic cylinder, double-acting, 16 mm bore, 200 mm stroke, M5, magnetic piston - Norgren KM/8016/MF/200

16 mm bore, 200 mm stroke and M5 port: the Norgren KM/8016/MF/200 is a double-acting stainless steel pneumatic cylinder for linear and positioning moves in automation.

Benefits in use

• The KM/8016/MF/200 follows ISO 6432 and fits designs laid out for this standard.
• Barrel and piston rod of the KM/8016/MF/200 are made of stainless steel, the barrel from 1.4301 and the rod from 1.4305.
• With its magnetic piston the KM/8016/MF/200 signals its position to cylinder switches without contact.
• From its 16 mm bore the KM/8016/MF/200 generates a theoretical 120 N at working pressures up to 10 bar.
• Elastic end buffers made of polyurethane soften the end stop of the KM/8016/MF/200.
• The KM/8016/MF/200 is rated for ambient temperatures from -10 to 80 °C.

Applications

The KM/8016/MF/200 suits lifting, pushing and clamping tasks on machines that call for stainless steel or are cleaned wet on a regular basis.
