Double-acting stainless steel pneumatic cylinder, 25 mm bore, 10 mm stroke, G1/8, magnetic piston - Norgren KM/8026/M/10

The Norgren KM/8026/M/10 is a double-acting stainless steel pneumatic cylinder with a 25 mm bore and 10 mm of stroke.

Benefits in use

• Cylinder switches detect the magnetic piston of the KM/8026/M/10 without contact, so the piston position can be monitored over 10 mm of stroke.
• With a 25 mm bore the KM/8026/M/10 reaches a theoretical force of 294 N according to the manufacturer data.
• The KM/8026/M/10 operates from 1 to 10 bar and therefore suits standard compressed air networks.
• The KM/8026/M/10 is rated for ambient temperatures from -10 to 80 °C.
• Adjustable end-position cushioning slows the piston of the KM/8026/M/10 before the stop and protects cylinder and machine.
• The KM/8026/M/10 has a barrel in stainless steel 1.4301 (X5CrNi18-10, AISI 304) and a piston rod in stainless steel 1.4305 (X10CrNiS18-9, AISI 303).

Applications

Typical tasks for the KM/8026/M/10 are linear drive tasks in machine and plant building where a stainless steel barrel is required, sized for 10 mm of stroke.
