Double-acting Lintra Lite cylinder, 32 mm bore, 305 mm stroke, with buffers - Norgren A44032AABAA/305

The Norgren A44032AABAA/305 is a double-acting Lintra Lite cylinder with 32 mm bore and 305 mm stroke. Travel and force of the A44032AABAA/305 follow from the 305 mm stroke and the piston area of the 32 mm bore. As the A44032AABAA/305 is double-acting, both the outstroke and the return stroke are powered by compressed air. Buffers at the end positions absorb the piston of the A44032AABAA/305 at the end of stroke.

Applications

The A44032AABAA/305 moves loads in a straight line, for example for pushing, lifting or clamping in fixtures and special machines. For replacement in an existing system the order code A44032AABAA/305 is sufficient, as it defines the version unambiguously.

Details on port, operating pressure and materials are not available for the A44032AABAA/305, please ask us before ordering.
