Double-acting Lintra Lite cylinder, 25 mm bore, 2236 mm stroke, with cushioning - Norgren A44025AADAA/2236

The A44025AADAA/2236 from Norgren is a double-acting Lintra Lite cylinder with 25 mm bore and 2236 mm stroke. Travel and force of the A44025AADAA/2236 follow from the 2236 mm stroke and the piston area of the 25 mm bore. As the A44025AADAA/2236 is double-acting, both the outstroke and the return stroke are powered by compressed air. Cushioning slows the piston of the A44025AADAA/2236 before the end positions and protects the cylinder and attached parts.

Applications

The A44025AADAA/2236 moves loads in a straight line, for example for pushing, lifting or clamping in fixtures and special machines. For replacement in an existing system the order code A44025AADAA/2236 is sufficient, as it defines the version unambiguously.

Details on port, operating pressure and materials are not available for the A44025AADAA/2236, please ask us before ordering.
