Double-acting tie rod cylinder, 2 inch bore, 190 mm stroke, G1/4 - Norgren RM/920/190

With a 2 inch (50.8 mm) bore and a 190 mm stroke, the Norgren tie rod cylinder RM/920/190 covers linear drive tasks in compressed air systems.

Benefits

• 2 inch (50.8 mm) bore on the RM/920/190 as the basis for force calculation
• 190 mm stroke on the RM/920/190 for the required travel
• Double-acting: the RM/920/190 is driven by compressed air in both directions
• G1/4 port on the RM/920/190 for the air supply
• Theoretical force of 1055 N on the RM/920/190 as a reference value for sizing
• Adjustable end cushioning on the RM/920/190 for smooth arrival in the end position

Applications

Typical tasks for the RM/920/190 are linear motion and clamping in pneumatics as well as replacement in existing Norgren installations.
