Double-acting tie rod cylinder, 1-3/4 inch bore, 90 mm stroke, G1/4 - Norgren RM/9175/90

The Norgren tie rod cylinder RM/9175/90 works with a 1-3/4 inch (44.45 mm) bore and a 90 mm stroke.

Benefits

• 1-3/4 inch (44.45 mm) bore on the RM/9175/90 as the basis for force calculation
• 90 mm stroke on the RM/9175/90 for the required travel
• Double-acting: the RM/9175/90 is driven by compressed air in both directions
• G1/4 port on the RM/9175/90 for the air supply
• Theoretical force of 812 N on the RM/9175/90 as a reference value for sizing
• Adjustable end cushioning on the RM/9175/90 for smooth arrival in the end position

Applications

The RM/9175/90 performs linear motion and clamping tasks in pneumatic systems and replaces identical Norgren cylinders.
