Double-acting pneumatic cylinder, 1-3/4 inch bore, 550 mm stroke, G1/4 - Norgren RM/9175/550
For linear motion and clamping tasks with compressed air, the Norgren pneumatic cylinder RM/9175/550 provides a 1-3/4 inch (44.45 mm) bore and a 550 mm stroke. Being double-acting, the RM/9175/550 extends and retracts under air pressure. The RM/9175/550 connects via G1/4 and operates from 2 to 10 bar.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren pneumatic cylinder RM/9175/550 is defined by a 1-3/4 inch (44.45 mm) bore and a 550 mm stroke.
Benefits
- 1-3/4 inch (44.45 mm) bore on the RM/9175/550 as the basis for force calculation
- 550 mm stroke on the RM/9175/550 for the required travel
- Double-acting: the RM/9175/550 is driven by compressed air in both directions
- G1/4 port on the RM/9175/550 for the air supply
- Theoretical force of 812 N on the RM/9175/550 as a reference value for sizing
- Adjustable end cushioning on the RM/9175/550 for smooth arrival in the end position
Applications
Typical tasks for the RM/9175/550 are linear motion and clamping in pneumatics as well as replacement in existing Norgren installations.
Technical data
| Design | pneumatic cylinder |
|---|---|
| Operation | double-acting |
| Bore | 1-3/4 inch (44.45 mm) |
| Stroke | 550 mm |
| Medium | compressed air |
| Pressure range | 2 to 10 bar |
| Ambient temperature | -20 to 80 °C |
| Port | G1/4 |
| End cushioning | adjustable |
| Magnetic piston | no |
| Theoretical force | 812 N |
| Barrel | anodised aluminium alloy |
| Bearing | die-cast aluminium |
| Seals | nitrile rubber (NBR) |
| Piston rod material | martensitic stainless steel |
| Piston | die-cast aluminium |
| Range | RM/900 |
| Series | Martonair |
| Norgren part number | RM/9175/550 |
| Customs tariff number | 84123100 |
| ECLASS | 51010101 |
| Weight | 0.1 kg |
| Manufacturer | Norgren |
| Hersteller-Nr | RM/9175/550 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Bauform | Pneumatikzylinder |
| Seal material | NBR |
| Housing material | Aluminium, anodised |
| Function | double-acting |
| Cushioning | adjustable |
| Betriebsdruck max [bar] | 10 |
| Pneumatic connection | G1/4 |
| Temperaturbereich | -20-80 °C |
| Temperature (max.) | 80 |
