Pneumatic cylinder, 1-1/4 inch bore, 35 mm stroke, G1/8, magnetic piston - Norgren RM/9125/M/35

Norgren ✓ Original product Brand new

As a replacement in Norgren installations, the pneumatic cylinder RM/9125/M/35 offers a 1-1/4 inch (31.75 mm) bore and a 35 mm stroke. The RM/9125/M/35 connects via G1/8 and operates from 2 to 10 bar. The magnetic piston of the RM/9125/M/35 allows end position sensing with cylinder switches.

Net
€723.88
excl. VAT
Item NRG-RM/9125/M/35
Manufacturer no. RM/9125/M/35
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Norgren pneumatic cylinder RM/9125/M/35 works with a 1-1/4 inch (31.75 mm) bore and a 35 mm stroke.

Benefits

  • 1-1/4 inch (31.75 mm) bore on the RM/9125/M/35 as the basis for force calculation
  • 35 mm stroke on the RM/9125/M/35 for the required travel
  • G1/8 port on the RM/9125/M/35 for the air supply
  • Theoretical force of 406 N on the RM/9125/M/35 as a reference value for sizing
  • Magnetic piston in the RM/9125/M/35 for contactless position sensing
  • Adjustable end cushioning on the RM/9125/M/35 for smooth arrival in the end position

Applications

The RM/9125/M/35 performs linear motion and clamping tasks in pneumatic systems and replaces identical Norgren cylinders.

Technical data

Designpneumatic cylinder
Bore1-1/4 inch (31.75 mm)
Stroke35 mm
Mediumcompressed air
Pressure range2 to 10 bar
Ambient temperature-20 to 80 °C
PortG1/8
End cushioningadjustable
Magnetic pistonyes
Theoretical force406 N
Barrelanodised aluminium alloy
Bearingdie-cast aluminium
Sealsnitrile rubber (NBR)
Piston rod materialmartensitic stainless steel
Pistondie-cast aluminium
RangeRM/900
SeriesMartonair
Norgren part numberRM/9125/M/35
Customs tariff number84123100
ECLASS51010101
Weight0.1 kg
ManufacturerNorgren
Hersteller-NrRM/9125/M/35
Zolltarifnummer84123100
GPSR HerstellerdatenNorgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
BauformPneumatikzylinder
Stroke [mm]35
Seal materialNBR
Housing materialAluminium, anodised
Cushioningadjustable
Betriebsdruck max [bar]10
Pneumatic connectionG1/8
Temperaturbereich-20-80 °C
Temperature (max.)80
