Double-acting tie rod cylinder, 10 inch bore, 345 mm stroke, G1 - Norgren RM/9100/345
For linear motion and clamping tasks with compressed air, the Norgren tie rod cylinder RM/9100/345 provides a 10 inch (254 mm) bore and a 345 mm stroke. Being double-acting, the RM/9100/345 extends and retracts under air pressure. The RM/9100/345 connects via G1 and operates from 2 to 10 bar.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren tie rod cylinder RM/9100/345 works with a 10 inch (254 mm) bore and a 345 mm stroke.
Benefits
- 10 inch (254 mm) bore on the RM/9100/345 as the basis for force calculation
- 345 mm stroke on the RM/9100/345 for the required travel
- Double-acting: the RM/9100/345 is driven by compressed air in both directions
- G1 port on the RM/9100/345 for the air supply
- Theoretical force of 28871 N on the RM/9100/345 as a reference value for sizing
- Adjustable end cushioning on the RM/9100/345 for smooth arrival in the end position
Applications
The RM/9100/345 performs linear motion and clamping tasks in pneumatic systems and replaces identical Norgren cylinders.
Technical data
| Design | tie rod cylinder |
|---|---|
| Operation | double-acting |
| Bore | 10 inch (254 mm) |
| Stroke | 345 mm |
| Medium | compressed air |
| Pressure range | 2 to 10 bar |
| Ambient temperature | -20 to 80 °C |
| Port | G1 |
| End cushioning | adjustable |
| Magnetic piston | no |
| Theoretical force | 28871 N |
| Barrel | anodised aluminium alloy |
| Bearing | die-cast aluminium |
| Seals | nitrile rubber (NBR) |
| Piston rod material | martensitic stainless steel |
| Piston | die-cast aluminium |
| Range | RM/900 |
| Series | Martonair |
| Norgren part number | RM/9100/345 |
| Customs tariff number | 84123100 |
| ECLASS | 51010101 |
| Weight | 0.1 kg |
| Manufacturer | Norgren |
| Hersteller-Nr | RM/9100/345 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Bauform | Zugstangenzylinder |
| Seal material | NBR |
| Housing material | Aluminium, anodised |
| Function | double-acting |
| Cushioning | adjustable |
| Betriebsdruck max [bar] | 10 |
| Pneumatic connection | G1 |
| Temperaturbereich | -20-80 °C |
| Temperature (max.) | 80 |
