Double-acting profile cylinder, 10 inch bore, 120 mm stroke, G1 - Norgren RM/9100/J/120

The Norgren profile cylinder RM/9100/J/120 works with a 10 inch (254 mm) bore and a 120 mm stroke.

Benefits

• 10 inch (254 mm) bore on the RM/9100/J/120 as the basis for force calculation
• 120 mm stroke on the RM/9100/J/120 for the required travel
• Double-acting: the RM/9100/J/120 is driven by compressed air in both directions
• G1 port on the RM/9100/J/120 for the air supply
• Theoretical force of 28871 N on the RM/9100/J/120 as a reference value for sizing
• Adjustable end cushioning on the RM/9100/J/120 for smooth arrival in the end position

Applications

Typical tasks for the RM/9100/J/120 are linear motion and clamping in pneumatics as well as replacement in existing Norgren installations.
