Double-acting pneumatic cylinder, 3 in bore, 800 mm stroke, G3/8 - Norgren RM/930/800

The Norgren RM/930/800 is a double-acting pneumatic cylinder with a 3 in (76.2 mm) bore and 800 mm of stroke. The theoretical force stated for the RM/930/800 is 2417 N.

Benefits in use

• Double-acting over 800 mm of stroke: the RM/930/800 moves in both directions under compressed air, no return spring needed.
• The RM/930/800 operates within a pressure range of 2 to 10 bar.
• With its 3 in bore the RM/930/800 reaches a theoretical force of 2417 N.
• The adjustable end-position cushioning of the RM/930/800 can be matched to load and speed at the end of its 800 mm stroke.
• The RM/930/800 is specified for ambient temperatures from -20 to 80 °C.

Applications

In fixture and machine building the RM/930/800 takes on linear motion and clamping tasks such as pushing, lifting or clamping.
