Double-acting pneumatic cylinder, 2-1/2 in bore, 130 mm stroke, G3/8 - Norgren RM/925/130

The Norgren RM/925/130 is a double-acting pneumatic cylinder with a 2-1/2 in (63.5 mm) bore and 130 mm of stroke. The theoretical force stated for the RM/925/130 is 1626 N.

Benefits in use

• Double-acting over 130 mm of stroke: the RM/925/130 moves in both directions under compressed air, no return spring needed.
• The RM/925/130 operates within a pressure range of 2 to 10 bar.
• With its 2-1/2 in bore the RM/925/130 reaches a theoretical force of 1626 N.
• The adjustable end-position cushioning of the RM/925/130 can be matched to load and speed at the end of its 130 mm stroke.
• The RM/925/130 is specified for ambient temperatures from -20 to 80 °C.

Applications

In fixture and machine building the RM/925/130 takes on linear motion and clamping tasks such as pushing, lifting or clamping.
